Excel VBA LBound Function

LBound in VBA stands for “Lower Bound.” It will extract the lowest number of an array. For example, if the array says “Dim ArrayCount (2 to 10) as String,” then using the LBound function, we can find the least number of the array length, i.e., 2.

Below is the syntax of the LBound function. It is very simple and easy. It has only two parameters.

Lbound (Array name [, dimension])
  • Array Name: This is the first argument. For this parameter, we need to specify the array’s name used to define the array.
  • [Dimension]: This is not required if the array is a single dimension. By default, it takes one, or we need to supply the dimension number.

So, using these functions, we can find the minimum length of an array.

VBA-LBound

You are free to use this image on your website, templates, etc, Please provide us with an attribution linkHow to Provide Attribution?Article Link to be Hyperlinked
For eg:
Source: VBA LBound (wallstreetmojo.com)

How to use the VBA LBound Function? (Example)

You can download this VBA LBound Excel Template here – VBA LBound Excel Template

Example #1

Look at the below code.

Code:

Sub LBound_Example1()

   Dim Count(2 To 5) As Integer

   MsgBox LBound(Count)

End Sub
VBA LBound Example 1

In the above code, we have defined the array as integer and the array size as 2 to 5. Next, we have assigned the VBA message box to show the lowest length of the array by using the LBound function.

When we run the code, we will get the below result in a message box.

Output:

 Example 1.1

Since our array starts from 2, the LBound function determines the lowest length of the array as 2.

–>> If you want to learn Excel VBA professionally, then our VBA Basic Course (16+ hours) is the perfect solution. In our Basic Excel VBA course you learn the skill of automating tasks using Variables, Data Types, Ranges, and Cells in VBA. Master Control Structures, including Conditional Statements and Loops, and discover techniques for manipulating data through sorting, filtering, and formatting. By the end of the course, you will be able to apply your acquired skills to real projects, culminating in an Excel VBA project which will solidify your ability to create efficient, automated solutions.

Example #2

Look at the below code.

Code:

Sub LBound_Example2()

  Dim Count(5) As Integer

  MsgBox LBound(Count)

End Sub
VBA LBound Example 2

In the above, we have not decided on the lowest limit. Rather, we just supplied the array length as 5 now. So, let us run the code and see the lowest length of the value.

Output:

 Example 2.1

It has returned the result as 0 because when we don’t decide the start and endpoint of an array, rather provide the static number, for example, “Count (5), i.e., in this case, array value starting from 0, not from 1. So, we can store a total of 6 values in it now.

Count (0), Count(1), Count(2), Count(3), Count(4), Count(5).

Example #3

Now, we will use the data range and decide the lower bound from the range of data. For example, look at the below data image.

VBA LBound Example 3

We will decide on the smallest and highest row size from this range.

First, define the variable as a variant.

Code:

Sub LBound_Example3()

  Dim Rng As Variant

End Sub
VBA LBound Example 3.1.0

For this “Rng” variant variable, set the range reference value as “Range (“B2: B5”).Value.”

Code:

Sub LBound_Example3()

  Dim Rng As Variant

  Rng = Range("B2:B5").Value

End Sub
VBA LBound Example 3.2

For this range, we will find the lowest and highest array length. Next, open the message box and LBound function and supply the variable name.

Code:

Sub LBound_Example3()

  Dim Rng As Variant

  Rng = Range("B2:B5").Value

  MsgBox LBound(Rng)

End Sub
Example 3.3

Now, run the VBA codeVBA CodeVBA code refers to a set of instructions written by the user in the Visual Basic Applications programming language on a Visual Basic Editor (VBE) to perform a specific task.read more and see the lowest value from the length.

Output:

VBA LBound Example 3.4

Now, change the variable reference from B2: B5 to A2: B5.

We will find the lower and upper bound values for this range.

Code:

Sub LBound_Example3()

  Dim Rng As Variant

  Rng = Range("A2:B5").Value

End Sub
 Example 3.5

Since we have more than one dimension array, we must also supply the dimension number.

Code:

Sub LBound_Example3()

  Dim Rng As Variant

  Rng = Range("A2:B5").Value

  MsgBox LBound(Rng, 1)

End Sub
Example 3.6

To find the first column first lower bound above code will help similarly. Likewise, finding the upper bound in this first column below the code will help.

Code:

Sub LBound_Example3()

  Dim Rng As Variant

  Rng = Range("A2:B5").Value

  MsgBox LBound(Rng, 1) & vbNewLine & UBound(Rng, 1)

End Sub
VBA LBound Example 3.7

It will find the first column’s lower length and upper length. Similarly, write one more message box in the next line but dimension from 1 to 2.

Code:

Sub LBound_Example3()

  Dim Rng As Variant

  Rng = Range("A2:B5").Value

  MsgBox LBound(Rng, 1) & vbNewLine & UBound(Rng, 1)

  MsgBox LBound(Rng, 2) & vbNewLine & UBound(Rng, 2)

End Sub
Example 3.8

Run the code and see the result in the message box.

Output:

VBA LBound Example 3.9

For the first dimension, the lower bound is 1, and the upper bound is 4.

Click on “OK” to get the next dimension limits.

Output:

 Example 3.10

The second dimension’s lower limit is 1, and the upper limit is 2.

Things to Remember here

  • The LBound function returns the minimum length from the array.
  • When the array length is static, i.e., a single number, the array always starts from the number 0, not from 1.
  • In the case of a multi-dimensional array, we need to specify the dimension number.
